MX08 Multichannel Weighing System, Technical Manual, Rev. 2.5 Page 101 of 144
40013 R 1
Calibration
Status
D0 .. D7
Calibration
Process
Status
1
System ready for calibration
3
Zero calibration in process
4
Span calibration in process
9 Error (Refer to D8 .. D15)
D8 .. D15
Calibration
Errors
1
Calibration Timeout
- Restart calibration
2
ADC Error
- Re-energize the instrument
3
Instrument can not be calibrating
- Check load cell cable
- Re-energize the instrument
34
Instrument can not be calibrating
- Load cell signal is very low
or too
high
35
Calibration Error
-
Calibration test weight is not
enough
-
Increase calibration weight value
(40011)
- Check load cell connections
37
Scale unstable
- Wait until scale becomes stable
- Check grounding wiring
40014 R/W 1
Operation
Mode
Selection
0
Count Mode Unipolar
1
Count Mode Bipolar
2
Force Mode Unipolar
3
Force Mode Bipolar
4
Weight Mode (Unipolar)
40015 R/W 1
Operation
mV of
Count Mode
0
5 mV
1
10 mV
2
15 mV
3
18 mV
40016 R/W 1
Digital
Filters
0
Fast
.
.
.
.
.
.
9
Slow
All MX08 AD uses the same register table like above.
Starting register address of all MX08 AD:
MX08 AD[0]: 40001
MX08 AD[1]: 40101
MX08 AD[2]: 40201
MX08 AD[3]: 40301
MX08 AD[4]: 40401
MX08 AD[5]: 40501
MX08 AD[6]: 40601
MX08 AD[7]: 40701
