MX08 Multichannel Weighing System, Technical Manual, Rev. 2.5 Page 100 of 144
Exception codes:
1: Function code is not supported
2 : Received data address is not in allowable address range
3 : Invalid value entrance or wrong byte number
4 : Operation error
MX08 EN Modbus TCP/IP Command Set 1:
The below register table is used for MX08 AD[0].
Address R/W Word Command Description
40001 R 2 Weight / Force / Count Data
40003 R 1 Status
D0
0 – System Ready 1 – System Busy
D1
0 – Error 1 – Data ok
D2
0 – Weight Stable 1 – Weight unstable
D3
0 – Gross Mode 1 – Net mode
D4
Not in use
D5
0 – Weight / Force 1 – Count Mode
D6 .. D11
Not in use
D12
0 – Out of zero range
1 – Weight is in zero range
D13
D14
D15
Error
Code
0
No Errors
1
ADC out of range
2
ADC overrange
3
ADC underrange
4
System error
5
In programming mode
6
Power supply is not in
required voltage range
7
No instrument found
40004 R 2 Tare weight
40006 R 2 Gross Weight
40008 R 1 Status Motion, Net mode, Data ok, (image of register 40003)
40009 R/W 1 Control
0
None
1
Zero
2
Tare
3
Clear
40010 R/W 1 Calibration
0
None
188
Adjust Zero Calibration
220
Adjust Span Calibration
40011 R/W 2 Span Calibration Value
