MX08 Multichannel Weighing System, Technical Manual, Rev. 2.5 Page 30 of 144
X
Syntax error ( not recognized the received command )
+
Overload
−
Underload
Note: CHK, CR and LF will not be shown in below data format descriptions in this section.
Address of N-Bus master instrument is 1 and address of N-Bus slave instrument is 2.
Commands and Responses:
A
Read all weight data
Command : [ADR][A]
Response : [ADR][A][STATUS][SIGN][NET W][SIGN][TARE W][SIGN][GROSS W]
Example :
Command : 12A
Response : 12AS+000123.4+000111.1+000234.5
12AD+000123.4+000111.1+000234.5
12AO ( ADC out error )
Comments :
The response is net, tare and gross weight values or error status.
All weight data is transmitted immediately after receiving the command.
B
Read Gross weight
Command : [ADR][B]
Response : [ADR][B][STATUS][SIGN][WEIGHT VALUE]
Example :
Command : 12B
Response : 12BS+000123.4 (gross weight is stable and 123.4)
12BD+000123.4 (gross weight is dynamic and 123.4)
12B (under load)
Comments :
The response is the gross weight value (stable or dynamic) or error status.
Gross weight data is transmitted immediately after receiving command.
C
Clear the tare memory
Command : [ADR][C]
Response : [ADR][C][A] )Cleared and the scale is in gross mode)
[ADR][C][X] (Unavailable in count mode)
Commends :
The response status is always Ack in weighing or force mode.
The response status is always X in count mode.
D
Read Count value immediately
Command : [ADR][D]
Response : [ADR][D][STATUS][SIGN][COUNT VALUE]
Example :
Command : 12D
Response : 12DD+00123400 or
: 12DO (ADC out error)
: 12DX (Not in count mode)
Comments : Count value is send immediately.
