MX08 Multichannel Weighing System, Technical Manual, Rev. 2.5 Page 31 of 144
I
Read indicated weight
Command : [ADR][I]
Response : [ADR][I][STATUS][SIGN][WEIGHT VALUE]
Example :
Command : 12I
Response : 12IS+000123.4 ( weight is stable and 123.4 )
12ID+000123.4 ( weight is dynamic and 123.4 )
12I+ ( overload )
Comments :
The response is the indicated weight value (stable or dynamic). It will be transmitted
immediately after receiving the command.
The weight value may be in gross or net.
P
Print : Read the stable weight
Command : [ADR][P]
Response : [ADR][P][STATUS][SIGN][WEIGHT VALUE]
Example :
Command : 12P
Response : 12PS+000123.4 (weight is stable and 123.4) or
12PN (could not print)
Comments :
Checks status and it must be stable. Else Nack status is send.
There is no time duration for stability checking.
Status can be Stable or Nack.
S
Read Status
Command : [ADR][S]
Response : [ADR][S][STATUS-1][STATUS-2][STATUS-3]
Example :
Command : 12S
Response : 12SSGI (Stable, Gross, In Range)
: 12SDGL (Dynamic, Gross, Low voltage error)
Comments :
The response is current 3 status information.
STATUS-1 can be Stable or Dynamic.
STATUS-2 can be Gross or Net.
STATUS-3 can be ‘in range’, ‘out of range’, ‘low voltage’ or ‘high voltage’.
T
Tare
Command : [ADR][T]
Response : [ADR][T][A] (Taring is done successfully and scale is in net)
[ADR][T][N] (Taring could not executed)
[ADR][T][X] (Taring is disabled or instrument is in count mode)
Comments :
The tare value is overwritten by the new tare weight value.
Status must be stable in 2 seconds time out delay. If so, Ack is send.
If it can not be stable in time out delay, Nack is send.
