MX08 Multichannel Weighing System, Technical Manual, Rev. 2.5 Page 32 of 144
U
Read digital inputs
Command : [ADR][U]
Response : [ADR][U][A][Inputs]
Example :
Command : 12U
Response : 12UA3 (Input 2 and Input 1 are active)
12UA4296 (Input 15,10,8,5,3,2 are active)
: 12UAFF (All 8 inputs are active)
: 12UN (Could not read inputs)
Comments :
Data length change according to number of digital inputs.
Inputs are implemented to ASCII char of 4-bit. ‘1111’ inputs are implemented to char ‘F’.
V
Read digital outputs
Command : [ADR][V]
Response : [ADR][V][A][Outputs]
Example :
Command : 12V
Response : 12VA3 (Output 2 and Output 1 are active)
12VA4296 (Output 15,10,8,5,3,2 are active)
: 12VAFF (All 8 outputs are active)
: 12VN (Could not read outputs)
Comments :
Data length change according to number of digital outputs.
Outputs are implemented to ASCII char of 4-bit. ‘1111’ outputs are implemented to char
‘F’.
INPUTS
IN
-16
IN
-15
IN
-14
IN
-13
IN
-12
IN
-11
IN
-10
IN
-9
IN
-8
IN
-7
IN
-6
IN
-5
IN
-4
IN
-3
IN
-2
IN
-1
Bit wise
0
1
0
0
0
0
1
0
1
0
0
1
0
1
1
0
ASCII
4
2
9
6
OUTPUTS
OUT
-16
OUT
-15
OUT
-14
OUT
-13
OUT
-12
OUT
-11
OUT
-10
OUT
-9
OUT
-8
OUT
-7
OUT
-6
OUT
-5
OUT
-4
OUT
-3
OUT
-2
OUT
-1
Bit wise
0
1
0
0
0
0
1
0
1
0
0
1
0
1
1
0
ASCII
4
2
9
6
