MX08 Multichannel Weighing System, Technical Manual, Rev. 2.5 Page 61 of 144
35
Calibration Error
-
Calibration test weight is not
enough
-
Increase calibration weight value
(40011)
- Check load cell connections
37
Scale unstable
- Wait until scale becomes stable
- Check grounding wiring
40014 R/W 1
Operation
Mode
Selection
0
Count Mode Unipolar
1
Count Mode Bipolar
2
Force Mode Unipolar
3
Force Mode Bipolar
4
Weight Mode (Unipolar)
40015 R/W 1
Operation
mV of
Count Mode
0
5 mV
1
10 mV
2
15 mV
3
18 mV
40016 R/W 1
Digital
Filters
0
Fast
.
.
.
.
.
.
9
Slow
40034 R 1
Voltage of
Power
Supply
Voltage of power supply is indicated with 0.1 V
increment. For example: 23.4 VDC is indicated as 234
value.
All MX08 AD uses the same register table like above.
Starting register address of all MX08 AD:
MX08 AD[0]: 40001
MX08 AD[1]: 40101
MX08 AD[2]: 40201
MX08 AD[3]: 40301
MX08 AD[4]: 40401
MX08 AD[5]: 40501
MX08 AD[6]: 40601
MX08 AD[7]: 40701
