MX08 MB Modbus RTU Command Set 2:
The below command set is recommended for fast communication.
Address R/W Word Command Description
41001 R 1
System
Status of
and
MX08 DP
00: No instrument found
01: 0 addressed MX08 AD is active
00: No instrument found
01: 1 addressed MX08 AD is active
00: No instrument found
01: 2 addressed MX08 AD is active
00: No instrument found
01: 3 addressed MX08 AD is active
00: No instrument found
01: 4 addressed MX08 AD is active
00: No instrument found
01: 5 addressed MX08 AD is active
00: No instrument found
01: 6 addressed MX08 AD is active
00: No instrument found
01: 7 addressed MX08 AD is active
41002 R 1
System
Status of
MX08 IO
D0
IO [0]
00 = 0 addressed no instrument found
01 = 0 addressed 4I / 4O is active
10 = 0 addressed 8I is active
11 = 0 addressed 8O is active
D1
D2
IO [1]
00 = 1 addressed no instrument found
01 = 1 addressed 4I / 4O is active
10 = 1 addressed 8I is active
11 = 1 addressed 8O is active
D3
D4
IO [2]
00 = 2 addressed no instrument found
01 = 2 addressed 4I / 4O is active
10 = 2 addressed 8I is active
11 = 2 addressed 8O is active
D5
D6
IO [3]
00 = 3 addressed no instrument found
01 = 3 addressed 4I / 4O is active
10 = 3 addressed 8I is active
11 = 3 addressed 8O is active
D7
D8
IO [4]
00 = 4 addressed no instrument found
01 = 4 addressed 4I / 4O is active
10 = 4 addressed 8I is active
11 = 4 addressed 8O is active
D9
D10
IO [5]
00 = 5 addressed no instrument found
01 = 5 addressed 4I / 4O is active
10 = 5 addressed 8I is active
11 = 5 addressed 8O is active
D11
D12
IO [6]
00 = 6 addressed no instrument found
01 = 6 addressed 4I / 4O is active
10 = 6 addressed 8I is active
11 = 6 addressed 8O is active
D13
D14
IO [7]
00 = 7 addressed no instrument found
01 = 7 addressed 4I / 4O is active
10 = 7 addressed 8I is active
11 = 7 addressed 8O is active
D15
41003 R 1
Gateway
Field bus communication error
