MX08 Multichannel Weighing System, Technical Manual, Rev. 2.5 Page 63 of 144
D3
An instrument is installed/removed in/from system
D4
Any instrument is not found in system
D5
..
D15
Not in use
41004
W
1
Not used
41005 R 1
MX08 AD
[0] Status
D0
0 – System Ready
1 – System Busy
D1
0 – Error
1 – Data OK
D2
0 – Weight Stable
1 – Weight not stable
D3
0 – Gross Mode
1 – Net mode
D4
Not in use
D5
0 – Weight/Force Mode
1 – Count Mode
D6
..
D11
Not in use
D12
0 – Out of Zero Range
1 – In Zero Range
D13
D14
D15
Error code
0
No Error
1
ADC out
2
ADC over
3
ADC under
4
System error
5
In programming mode
6
Power supply is not in required
voltage range
7
No instrument found
41006
R
2
MX08 AD [0] Indicated Weight
41008
R
2
MX08 AD [0] Gross Weight
41010
R
2
MX08 AD [0] Tare Weight
41012
R
1
MX08 AD [1] Status
41013
R
2
MX08 AD [1] Indicated Weight
41015
R
2
MX08 AD [1] Gross Weight
41017
R
2
MX08 AD [1] Tare Weight
41019
R
1
MX08 AD [2] Status
41020
R
2
MX08 AD [2] Indicated Weight
41022
R
2
MX08 AD [2] Gross Weight
41024
R
2
MX08 AD [2] Tare Weight
41026
R
1
MX08 AD [3] Status
41027
R
2
MX08 AD [3] Indicated Weight
41029
R
2
MX08 AD [3] Gross Weight
41031
R
2
MX08 AD [3] Tare Weight
41033
R
1
MX08 AD [4] Status
41034
R
2
MX08 AD [4] Indicated Weight
41036
R
2
MX08 AD [4] Gross Weight
41038
R
2
MX08 AD [4] Tare Weight
41040
R
1
MX08 AD [5] Status
41041
R
2
MX08 AD [5] Indicated Weight
41043
R
2
MX08 AD [5] Gross Weight
41045
R
2
MX08 AD [5] Tare Weight
41047
R
1
MX08 AD [6] Status
41048
R
2
MX08 AD [6] Indicated Weight
41050
R
2
MX08 AD [6] Gross Weight
