MX08 Multichannel Weighing System, Technical Manual, Rev. 2.5 Page 87 of 144
Bit
Number
2
nd
, 4
th
, 6
th
, 8
th
, 10
th
, 12
th
, 14
th
, 16
th
Dword descriptions when Read Command is ‘Calibration
Status’. Refer to PLC Output to MX08 PN Input for 3
rd
Dword
D31
…
D16
Not in use
D15
D14
D13
D12
D11
D10
D9
D8
0000 0001
Calibration Timeout
- Restart calibration
Calibration Status
0000 0010
ADC Error
- Re-energize the instrument
0000 0011
Instrument can not be calibrating
- Check load cell cable
- Re-energize the instrument
0010 0010
Instrument can not be calibrating
- Load cell signal is very low or too high
0010 0011
Calibration Error
- Calibration test weight is not enough
- Increase calibration weight value
- Check load cell connections
0010 0101
Scale unstable
- Wait until scale become stable
- Check grounding wiring
D7
D6
D5
D4
D3
D2
D1
D0
0000 1001 Calibration Errors
Calibration Process
Status
0000 0100 Span calibration in process
0000 0011 Zero calibration in process
0000 0001 System ready for calibration
Register address for
MX08 AD[1]: 4
th
– 5
th
Dwords
MX08 AD[2]: 6
th
– 7
th
Dwords
MX08 AD[3]: 8
th
– 9
th
Dwords
MX08 AD[4]: 10
th
– 11
th
Dwords
MX08 AD[5]: 12
th
–13
th
Dwords
MX08 AD[6]: 14
th
– 15
th
Dwords
MX08 AD[7]: 16
th
–17
th
Dwords definitions are same as 2
nd
– 3
rd
Dwords
MX08 IO[x]
Byte D7
D6
D5
D4
D3
D2
D1
D0
MX08 IO[0]
+1
st
Byte
Input 4
Input 3
Input 2
Input 1
MX08 IO[1]
+2
nd
Byte
Input 4
Input 3
Input 2
Input 1
MX08 IO[2]
+3
rd
Byte
Input 4
Input 3
Input 2
Input 1
MX08 IO[3]
+4
th
Byte
Input 4
Input 3
Input 2
Input 1
MX08 IO[4]
+5
th
Byte
Input 4
Input 3
Input 2
Input 1
MX08 IO[5]
+6
th
Byte
Input 4
Input 3
Input 2
Input 1
MX08 IO[6]
+7
th
Byte
Input 4
In
put 3
Input 2
Input 1
MX08 IO[7]
+8
th
Byte
Input 4
Input 3
Input 2
Input 1
