MX08 Multichannel Weighing System, Technical Manual, Rev. 2.5 Page 88 of 144
PLC Output to MX08 PN Input
Bitwise of Dword:
Dword
(R/W)
D31
D30
D29
D28
D27
D26
D25
D24
D23
D22
D21
D20
D19
D18
D17
D16
D15
D14
D13
D12
D11
D10
D9
D8
D7
D6
D5
D4
D3
D2
D
1
D0
MX08
PN
1
st
Dword
(W)
Not in use
Not in use
I/O
Write
Common Command
List
Not in use
New
CMD
Bit Number 1
st
Dword Description
D31 … D9
Not in use
D8
0: Input / Outputs change over PLC Output to MX08 PN Input I/O Bytes. This
flag does not need to New CMD command.
I/O Write
Control
1: Input / Outputs are change over Common Command List below.
1001: RESET, 1000: SET Outputs.
D7
D6
D5
D4
0000
None
Common
Command
List
0001
Zeroing command sent to all Digitizers.
0010
Tare command sent to all Digitizers.
0011
Clear command sent to all Digitizers.
1000
SET all I/O outputs. (if I/O Write Control = 1)
1001
RESET all I/O outputs. (if I/O Write Control = 1)
D3 … D1
Not in use
D0
Toggle
Apply commands which are listed in this table.
New CMD
MX08
AD[0]
2
nd
Dword
(W)
Next Dword defines the usage of this Dword.
3
rd
Dword
(W)
Not in use
Not in use
Command List
Description of 2
nd
Dword (R)
New
CMD
Bit Number 3
rd
, 5
th
, 7
th
, 9
th
, 11
th
, 13
th
, 15
th
, 17
th
Dword Description
D31 … D11
Not in use
