MX08 Multichannel Weighing System, Technical Manual, Rev. 2.5 Page 89 of 144
D10
D9
D8
D7
D6
00000
None command selected
Command
List
00001
Zero
00010
Tare
00011
Clear
00101
Start zero calibration.
00110
Start span calibration. First, load 2
nd
Dword with test weight
value, then apply this command with New CMD.
01000
Operation Mode Selection. First, load 2
nd
Dword with selected
value, then apply this command with New CMD.
0 = Count mode unipolar, 1 = Count mode bipolar
2 = Force mode unipolar, 3 = Force mode bipolar,
4 = Weight mode unipolar
01001
Operation mV of Count Mode. First, load 2
nd
Dword with selected
value, then apply this command with New CMD.
0 = 5mV, 1 = 10mV, 2 = 15mV, 3 = 18mV
01010
Digital Filter. First, load 2
nd
Dword with selected value, then
apply this command with New CMD.
Filter Values: 0 = Fast, … , 9 = Slow.
D5
D4
D3
D2
D1
00000
Indicated weight
Description of
2
nd
Dword (R)
00001
Gross weight
00010
Tare weight
00011
Indicated weight (floating point type)
00100
Gross weight (floating point type)
00101
Tare weight (floating point type)
10000
Calibration Status
D0
Toggle
Apply commands which are listed in this table.
New CMD
Register address for
MX08 AD[1]: 4
th
– 5
th
Dwords
MX08 AD[2]: 6
th
– 7
th
Dwords
MX08 AD[3]: 8
th
– 9
th
Dwords
MX08 AD[4]: 10
th
– 11
th
Dwords
MX08 AD[5]: 12
th
–13
th
Dwords
MX08 AD[6]: 14
th
– 15
th
Dwords
MX08 AD[7]: 16
th
–17
th
Dwords definitions are same as 2
nd
– 3
rd
Dwords
MX08 IO[x]
Byte (W) D7
D6
D5
D4
D3
D2
D1
D0
MX08 IO[0]
+1
st
Byte (W)
Output 4
Output 3
Output 2
Output 1
MX08 IO[1]
+2
nd
Byte (W)
Output 4
Output 3
Output 2
Output 1
MX08 IO[2]
+3
rd
Byte (W)
Output 4
Output 3
Output 2
Output 1
MX08 IO[3]
+4
th
Byte (W)
Output 4
Output 3
Output 2
Output 1
MX08 IO[4]
+5
th
Byte (W)
Output 4
Output
3
Output 2
Output 1
MX08 IO[5]
+6
th
Byte (W)
Output 4
Output 3
Output 2
Output 1
MX08 IO[6]
+7
th
Byte (W)
Output 4
Output 3
Output 2
Output 1
MX08 IO[7]
+8
th
Byte (W)
Output 4
Output 3
Output 2
Output 1
