TotalAlert Innity™ HTM Medical Gas Notication System
4107 9016 60.01
A3 - ___
B
Available Gas Sensors
Description
Oxygen
Nitrous Oxide
Medical Air
Medical Vacuum
Nitrogen
Carbon Dioxide (CO2)
HE-O2 (HE over 80%)
Laboratory Air
Laboratory Vacuum
Surgical Air
O2-N2O
Example: TotalAlert Innity™ Central Alarm with 20 Inputs and 16 Relay
Outputs Example Model Number: A3-M11
Example: TotalAlert Innity™ Area Alarm with 4 gases - Oxygen, Nitrous
Oxide, Medical Air, and Vacuum
Example Model Number: A3-A10
* Gas sensors to be ordered separately
Example: TotalAlert Innity™ Combination Alarm with 20 Inputs, and 3
gases - Oxygen, Medical Air, and Vacuum
Example Model Number: A3-C10
* Gas sensors to be ordered separately
Example: TotalAlert Innity™ Combination Alarm with four 4-420mA
devices and 6 Relay Outputs.
Example Model Number: A3-C40
1.7 TotalAlert Innity™ Medical Gas Notication System Parent Model
Number Chart
Variable B
Alarm Type and Size
Allowable
Value
Description
A10 Area Alarm, Up to 8 Area Gases
M01 Central, 0 Inputs, 16 Relay Outputs
M02 Central, 0 Inputs, 32 Relay Outputs
M10 Central, 20 Inputs
M11 Central, 20 Inputs, 16 Relay Outputs
C10 Combination, 20 Inputs, Display up to
6 Area Gases
C40 Combination, 4 Inputs for 4-20 mA
devices, 6 Relay Outputs
Recommended separation distances between
portable and mobile RF communications equipment and the TotalAlert Innity
The TotalAlert Innity is intended for use in the electromagnetic environment in which radiated
RF disturbances are controlled. The customer or the user of the TotalAlert Innity can help
prevent electromagnetic interference by maintaining a minimum distance between portable
and mobile RF communications equipment (transmitters) and the TotalAlert Innity as recom-
mended below, according to the maximum output power of the communications equipment.
Rated maximum output
power of transmitter
W
Separation distance according to frequency of transmitter
m
150 kHz to
80 MHz
d = 1,2√P
80 MHz to 800 MHz
d = 1,2√P
800 MHz to 2,5 GHz
d = 2,3√P
0,01 0,12 0,12 0,23
0,1 0,38 0,38 0,73
1 1,2 1,2 2,3
10 3,8 3,8 7,3
100 12 12 23
For transmitters rated at a maximum output power not listed above, the recommended sepa-
ration distance d in metres (m) can be estimated using the equation applicable to the frequency
of the transmitter, where P is the maximum output power rating of the transmitter in watts (W)
according to the transmitter manufacturer.
Note 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
Note 2 These guidelines may not apply in all situations. Electromagnetic propagation is aected
by absorption and reection from structures, objects and people.
