TotalAlert Innity™ HTM Medical Gas Notication System
4107 9016 60.01
1.5 Alarm Congurations
All TotalAlert Innity™ alarm panels are factory
pre-congured. Conguration of alarm panel varies
dependent upon customer’s requirements.
Three types of alarm panels are available.
• Central alarms
• Area alarms
• Combination alarms
General Fault Relay
Single-pole single-throw dry-contact relay output. Used
to activate remote alarm or building management
system. Relay will open whenever ANY audible alarm
on panel is in progress. General Fault Relay will close
only after alarm condition is corrected and alarm panel
resumes normal status.
Hyper Text Transfer Protocol (HTTP)
Protocol used to manage the request and transfer of
web pages to a computer.
Internet Protocol (IP) Address
Unique number that identies a device on a network.
LED
Light Emitting Diode
Media Access Control (MAC) Address
A unique hardware address of a device on an
Ethernet.
NetBIOS Name Service
Local method of addressing a device by name. This
allows a web browser to reference a device by name
instead of an IP address, such as 192.168.2.3.
Remote Sensors
Pressure / vacuum sensors mounted outside of alarm
panel back box. Sensor assemblies may be mounted
separately or ganged together near pressure / vacuum
pipelines. Sensors must then be wired to alarm panel.
Simple Mail Transfer Protocol (SMTP)
Protocol for sending e-mail on a network.
Subnet Mask
A binary number used to separate the network portion
from the host portion of a network address.
SMTP Client
Computer or device that uses SMTP to send e-mail by
communicating with an SMTP server. The TotalAlert
Innity™ Medical Gas Notication System acts as an
SMTP client.
SMTP Server
Computer or device that uses SMTP to receive e-mail
from an SMTP client and then transfer it across the
internet.
Transmission Control Protocol (TCP)
Protocol used to send data streams between two de-
vices. TCP guarantees reliable and in order data from
sender to receiver.
User Datagram Protocol (UDP)
Protocol used to send short messages between com-
puters. UDP does not guarantee reliable transmission
(packets may be lost, duplicated or out of order), but is
faster and more ecient than TCP.
Figure 1.10: Central Alarm Front Panel
1.5.1 Central Alarms
Central alarm panels include the following modular
components:
• Signal input board (B30) that can accept 20 signals
per board; maximum of 1 board.
• Relay boards (B40, B41) that can be used to control
16 dry-contact signals per board; maximum of 2
boards.
Central alarm panels can monitor 20 switched inputs.
Inputs can be assigned to any gas service indicators.
Model Number Scheme:
____ - _______ - ____
Series - Conguration - Retrot
See Model Number Chart in Section 1.7.
Example:
TotalAlert Innity™ Central 20X 16Y
Example Model Number: A3-M11
