Installation
Configuration Setup
DV14307.03 Issue 04 March 2016 Transceiver Family 620X 59
On "AUTO AUX ATT" page the attenuation for the auxiliary audio input
can be adjusted between 0...40 dB by turning the "ROTARY
ENCODER"
When intercommunication is initiated (regardless of the intercom
activation: "VOX", or "/IC" discrete input) the signal from auxiliary audio
input will be attenuated. After intercommunication is finished the
auxiliary audio will revert to its previous level.
Note: Menu available on primary controller.
On "IN/OUT CFG 1" page the microphone inputs and headphone
outputs for configuration CFG1 can be configured.
To scroll the page turn the "ROTARY ENCODER".
MICROPHONE 1
○ STD 1 MIKE
○ STD 2 MIKE
○ STD 3 MIKE
● DYN MIKE
○ NONE
MICROPHONE 2
○ STD 1 MIKE
○ STD 2 MIKE
○ STD 3 MIKE
○ DYN MIKE
● NONE
MIC ACTIVATION
BOTH MIKES
OUTPUTS
HEADPHONE 1
○ HEADPHONE 1
● SPEAKER
○ NONE
IN/OUT CFG 1
"MICROPHONE 1" (at one time only one option can be selected):
STD1 MIKE
Standard microphone input 1 (Pins P1-18/ P1-8) is selected.
STD2 MIKE
Standard microphone input 2 (Pins P1-9/ P1-8) is selected.
STD3 MIKE
Standard microphone input 3 (Pins P1-19/ P1-8) is selected.
DYN MIKE
Dynamic microphone input (Pins P1-6/ P1-5) is selected.
NONE
No microphone is used in microphone path 1.
"MICROPHONE 2" (at one time only one option can be selected):
STD1 MIKE
Standard microphone input 1 (Pins P1-18/ P1-8) is selected.
STD2 MIKE
Standard microphone input 2 (Pins P1-9/ P1-8) is selected.
STD3 MIKE
Standard microphone input 3 (Pins P1-19/ P1-8) is selected.
DYN MIKE
Dynamic microphone input (Pins P1-6/ P1-5) is selected.
NONE
No microphone is used in microphone path 2.
"MIC ACTIVATION"
BOTH MIKES ENABLED:
Input /PTT1 (Pin P1-17) activates transmission from microphone path 1
and 2.
Input /PTT2 (Pin J1-5) activates transmission from microphone path 2
and path 1.
Input /IC (Pin P1-7) activates intercom from microphone path 1 and 2.
BOTH MIKES DISABLED:
Input /PTT1 (Pin P1-17) activates transmission only from microphone
path 1
Input /PTT2 (Pin J1-5) activates transmission only from microphone
