Error correction
EL72x1176 Version: 3.3
Text ID Type Place Text Message Additional comment
0x8288 Error Communication Reading Certificate EK
failed: %X
0x8289 Error Communication Challenge could not be
hashed: %X
0x828A Error Communication Tickstamp Process failed
0x828B Error Communication PCR Process failed: %X
0x828C Error Communication Quote Process failed:
%X
0x82FF Error Communication Bootmode not activated Boot mode not activated
0x8300 Error Encoder Set position error: 0x%X,
%d
Error while setting the position
0x8301 Error Encoder Encoder increments not
configured: 0x%X, %d
Encoder increments not configured
0x8302 Error Encoder Encoder error The amplitude of the resolver is too small
0x8303 Error Encoder Encoder supply error Encoder power supply unit error
0x8304 Error Encoder Encoder communication
error, channel: %X
Encoder communication error
0x8305 Error Encoder EnDat2.2 is not sup-
ported, channel: %X
EnDat2.2 is not supported
0x8306 Error Encoder Delay time, tolerance
limit exceeded, 0x%X,
channel: %X
Runtime measurement, tolerance exceeded
0x8307 Error Encoder Delay time, maximum
value exceeded, 0x%X,
channel: %X
Runtime measurement, maximum value exceeded
0x8308 Error Encoder Unsupported ordering
designation, 0x%X,
channel: %X (only 02
and 22 is supported)
Wrong EnDat order ID
0x8309 Error Encoder Encoder CRC error,
channel: %X
Encoder CRC error
0x830A Error Encoder Temperature %X could
not be read, channel:
%X
Temperature cannot be read
0x8400 Error Drive Incorrect drive configura-
tion: 0x%X, %d
Drive incorrectly configured
0x8401 Error Drive Limiting of calibration ve-
locity: %d, %d
Limitation of the calibration velocity
0x8402 Error Drive Emergency stop acti-
vated: 0x%X, %d
Emergency stop activated
0x8403 Error Drive ADC Error Error during current measurement in the ADC
0x8404 Error Drive Overcurrent Overcurrent in phase U, V or W
0x8405 Error Drive Invalid modulo position:
%d
Modulo position invalid
0x8406 Error Drive DC-Link undervoltage
(Error)
The DC link voltage of the terminal is lower than the
parameterized minimum voltage. Activation of the out-
put stage is prevented
0x8407 Error Drive DC-Link overvoltage (Er-
ror)
The DC link voltage of the terminal is higher than the
parameterized maximum voltage. Activation of the out-
put stage is prevented
0x8408 Error Drive I2T-Model Amplifier
overload (Error)
- The amplifier is being operated outside the specifica-
tion
- The I2T-model of the amplifier is incorrectly parame-
terized
0x8409 Error Drive I2T-Model motor over-
load (Error)
- The motor is being operated outside the parameter-
ized rated values
- The I2T-model of the motor is incorrectly parameter-
ized
0x840A Error Drive Overall current threshold
exceeded
Total current exceeded
0x8415 Error Drive Invalid modulo factor:
%d
Modulo factor invalid
0x8416 Error Drive Motor overtemperature The internal temperature of the motor exceeds the pa-
rameterized error threshold. The motor stops immedi-
ately. Activation of the output stage is prevented.
0x8417 Error Drive Maximum rotating field
velocity exceeded
Rotary field speed exceeds the value specified for dual
use (EU 1382/2014).
