Error correction
EL72x1 175Version: 3.3
Text ID Type Place Text Message Additional comment
0x8000 Error System %s: %s
0x8001 Error System Error: 0x%X, 0x%X, 0x
%X
General error; parameters depend on event. See de-
vice documentation for interpretation.
0x8002 Error System Communication aborted Communication aborted
0x8003 Error System Configuration error: 0x
%X, 0x%X, 0x%X
General; parameters depend on event.
See device documentation for interpretation.
0x8004 Error System %s: Unsuccessful Fw-
dOpen-Response re-
ceived from %d.%d.%d.
%d (%s) (Error: %u)
0x8005 Error System %s: FwdClose-Request
sent to %d.%d.%d.%d
(%s)
0x8006 Error System %s: Unsuccessful Fwd-
Close-Response re-
ceived from %d.%d.%d.
%d (%s) (Error: %u)
0x8007 Error System %s: Connection with %d.
%d.%d.%d (%s) closed
0x8100 Error General Status word set: 0x%X,
%d
Error bit set in the status word
0x8101 Error General Operation mode incom-
patible to PDO interface:
0x%X, %d
Mode of operation incompatible with the PDO interface
0x8102 Error General Invalid combination of In-
puts and Outputs PDOs
Invalid combination of input and output PDOs
0x8103 Error General No variable linkage No variables linked
0x8104 Error General Terminal-Overtempera-
ture
The internal temperature of the terminal exceeds the
parameterized error threshold. Activation of the termi-
nal is prevented
0x8105 Error General PD-Watchdog Communication between the fieldbus and the output
stage is secured by a Watchdog. The axis is stopped
automatically if the fieldbus communication is inter-
rupted.
- The EtherCAT connection was interrupted during op-
eration
- The Master was switched to Config mode during op-
eration
0x8135 Error General Cycle time has to be a
multiple of 125 µs
The IO or NC cycle time divided by 125 µs does not
produce a whole number
0x8136 Error General Configuration error: in-
valid sampling rate
Configuration error: Invalid sampling rate
0x8137 Error General Electronic type plate:
CRC error
Content of the external name plate memory invalid.
0x8140 Error General Sync Error Real-time violation
0x8141 Error General Sync%X Interrupt lost Sync%X Interrupt lost
0x8142 Error General Sync Interrupt asynchro-
nous
Sync Interrupt asynchronous
0x8143 Error General Jitter too big Jitter limit violation
0x817F Error General Error: 0x%X, 0x%X, 0x
%X
0x8200 Error Communication Write access error: %d,
%d
Error while writing
0x8201 Error Communication No communication to
field-side (Auxiliary volt-
age missing)
- There is no voltage applied to the power contacts
- A firmware update has failed
0x8281 Error Communication Ownership failed: %X
0x8282 Error Communication To many Keys founded
0x8283 Error Communication Key Creation failed: %X
0x8284 Error Communication Key loading failed
0x8285 Error Communication Reading Public Key
failed: %X
0x8286 Error Communication Reading Public EK
failed: %X
0x8287 Error Communication Reading PCR Value
failed: %X
