Belden thinklogical SMP2 - SMP Hardware General Technical Specifications

System Management Portfolio 2.0 Product Manual Rev. C, Feb. 2020
Page 18
SMP Appliance Technical Specifications
PHYSICAL
(See Appendix A on pg. 65 for part numbers)
Rack-Mountable
Chassis Dimensions
Rack Size: EIA 19” (482.6 mm)
Depth: 14.00” (355.6 mm)
Width: 17.47” (443.8 mm)
Height: 1.72” (43.7 mm)
Weight: 9.5 lbs. (4.32 kg)
Shipping Weight: 18 lbs. (8.2 kg)
Interfaces
Front Panel:
1 USB-mini Firmware Updates
2 LEDs Power Indicators
1 LCD/Nav. Buttons System Menu Navigation
Rear Panel:
1 HDMI-A Local Monitor
3 USB-A Local Keyboard/Mouse/Firmware
1 DB-9 Console Port
(5) SFPs Fiber connections to/from Matrix Switch
8 GbE MagJack Gigabit Ethernet
2 AC IN Power
ELECTRICAL
Input Rating
100-240VAC, 1.5A, 50-60Hz (current to nearest 0.1A)
Max. DC Power
Consumption
80 Watts max. (Equal to max. output of a single Power Supply.)
-
SMP Module/Client Technical Specifications
PHYSICAL
(See Appendix A on pg. 65 for part numbers)
Rack-Mountable
Chassis Dimensions
Depth: 6.875” (174.6 mm)
Width: 3.693” (93.8 mm)
Height: 1.72” (43.7 mm)
Weight: .646 lbs. (.293 kg)
Shipping Weight: 2.0 lbs. (.907 kg)
Interfaces
1 USB-mini Firmware Updates
1 HDMI-A Video Out
2 USB-A Local Keyboard/Mouse/Firmware
1 DB-9 Serial Console Port
1 SFP Fiber connections to/from Matrix Switch
2 LEDs Valid-signal Indicators
1 RJ45 MGMT
1 Reset Return-to-Default Button
ELECTRICAL
Input Rating
100-240VAC, 1.5A, 50-60Hz (current to nearest 0.1A)
Max. DC Power
Consumption
20 Watts max. (Equal to max. output of a single Power Supply.)
