Double End Of Line — The Zone in standby status
when two 10 Kohms resistors (brown-black-or
-
ange-gold) are connected in parallel between the
zone terminal and negative.
If one of the resistors disconnects, the Control Panel
will generate the events associated with the Zone Type
(refer to “Type”). In all other cases (Zone Open, Con
-
nected to Negative, etc.), the Control Panel will detect
Tamper conditions and generate the following events:
Ø
Tamper on zone (relative to the zone concerned);
Ø
Tamper alarm on partition relevant to the Partition
the Zone is assigned to.
This Balance Type (using 2 wires) will allow the sys
-
tem to detect open Alarm and Tamper contacts (re
-
fer to “Connecting to a Double Balance zone”).
r
Triple End of Line — In addition to detecting and
signalling the alarm and tamper as in the Double
End of Line Balance this type of balance allows you
to detect and signal Grade 3 sensor faults:
Ø
a Grade 3 sensor fault is reported by the event Sys
-
tem > Zone Fault/Masking.
+
This event does NOT discriminate the fault zone;
this information can be viewed on the keypads
(Viewing Signals and Event Log).
If you select this Balance, the detector must be con
-
nected as described in par. “INSTALLING > Connection
of Grade 3 detectors”.
3
This Balance is only available for Grade 3 Control
Panels.
Wireless Device Serial Number This option is for the
ESN (Electronic Serial Number) of the Wireless detec-
tor which is assigned to the selected Zone.
+
You cannot program the device parameters until
you have entered its ESN.
The ESN will allow the Control Panel to identify the wire
-
less device on the system.
+
Some Wireless Devices have 5-digit and 6-digit
ESNs (printed on back), use ONLY 6-digit ESNs
with this Control Panel.
r
Replacing Wireless Detector — To replace a Wire
-
less detector (assigned to a Zone): select the required
Zone, then enter the ESN of the new Wireless detec
-
tor in the Wireless Device Serial Number option.
r
Enrolling Wireless Detector — To enrol a Wireless
detector: select an empty Zone, then enter the Wire
-
less detector ESN in the Wireless Device Serial
Number option.
r
Unenrolling Wireless Detector — To unenrol a
Wireless detector (assigned to a Zone): select the re
-
quired Zone then enter 000000 in the Wireless De
-
vice Serial Number option.
Wireless-Supervision If this option is Enabled, the
system will be able to signal the loss of the Wireless de
-
tector. The Receiver will trigger the Lost wireless zone
event as soon as the programmed Supervisory time ex
-
pires (refer to the Time supervision zones under “Ac
-
cessories” in the “Configuration” section). The place
-
ment of Wireless detector will not be indicated, how
-
ever, the respective information will be recorded in the
log.
Type The Type determines the affect the Armed/Dis
-
armed status of the partitions will have on the Alarm sig
-
nals, and whether the Zone will trigger Alarms immedi
-
ately or after a programmed delay.
+
All Zones — other than Fire and 24h — will be clas
-
sified as Burglar.
r
Instant — Violation (refer to “Balance” and “Sensi
-
tivity”) of an Instant Zone — that is not Unbypassed or
in Test status (refer to “Attributes”); has not run its pro
-
grammed Cycles (refer to “Cycles”), and whose Parti
-
tions are Armed — will generate the following events:
Ø
Alarm on zone (related to the Zone concerned);
Generic alarm on partition — relative to the Armed
Partitions of the Zone.
r
Entry delay — Violation of an Entry Delay Zone —
that is not Unbypassed or in Test status; has not run
its programmed Cycles, and whose Partitions are
Armed — will trigger the longest Entry Delay of all of
its Partitions. All the associated Keypads will beep
until the delay expires. If the Partitions the Zone is
assigned to are not Disarmed before the delay ex-
pires, or if the Zone is violated after the Delay, the
system will generate the Events like an Instant
Zone.
The first Zone on the path to a Disarm point (Reader
or Keypad) should be programmed as an Entry de
-
lay Zone.
r
Entry path — Violation of an Entry path Zone will
generate the events like an Instant Zone, unless
during the Entry Delay of its Partition (and also un
-
less the zone is bypassed or in Test status or has run
its programmed Cycles).
Violation of an Entry path Zone — during the Entry
Delay of its Partition — will not trigger any events.
The Zones leading to a Disarm point (Reader or Key
-
pad) should be programmed as Entry path Zones.
r
Exit delay — Violation of an Exit delay Zone — dur
-
ing the Exit Delay of its Partition — will not trigger
any events. In all other cases, the system will gener
-
ate the Events like an Instant Zone (unless the zone
is bypassed or in Test status or has run its pro
-
grammed Cycles).
The Zones leading out of a Partition should be pro
-
grammed as Exit delay Zones.
44 Expandable Hybrid Control Panel
