Last exit — Violation of a Last Exit Zone — during
the Exit Delay of its Partition — will not generate any
Events but will replace any residual Exit Delay, and
trigger the programmed Last Exit Time of its Parti
-
tion.
In all other cases, the system will generate the
Events like an Instant Zone (unless the zone is by
-
passed or in Test status or has run its programmed
Cycles).
This feature will allow the system to Arm as soon as
the programmed Last Exit Time expires.
The last Zone leading out of a Partition should be
programmed as a Last Exit Zone.
r
24 hr — Violation of a 24h Zone — regardless of the
status of its Partition — will generate the Events like
an Instant Zone (unless the zone is bypassed or in
Test status or has run its programmed Cycles).
24hr Zones can be used for control applications,
such as switching on courtesy lights (using infrared
sensors).
r
Fire — This type of zone is automatically pro
-
grammed as a 24h, N.O. (Normally Open) zone. Vio
-
lation of a Fire Zone — regardless of the status of its
Partition — will generate the following events:
Ø
Alarm on zone (relevant to the Zone concerned);
Ø
Generic alarm on partition — relevant to the Parti
-
tion the Zone is assigned to.
r Hold-up — Violation of an Hold-up Zone — regard-
less of the status of its Partition — will generate
Events like an Instant Zone (unless the zone is by-
passed or in Test status or has run its programmed
Cycles). Moreover:
Ø events generated by the Hold-up zone CANNOT ac-
tivate output n. 1;
Ø the Keypad WILL NOT signal Alarms triggered by
Hold-up Zones (the a indicator WILL NOT blink);
Ø the Keypad WILL NOT signal outgoing calls triggered
by Hold-up Zones by mean of the event Alarm on
zone ( WILL NOT appear above the i icon).
A
If a Hold-up zone is active, the EN50131 and
EN50131-3-1 standards require that the arming
can’t be performed. Forced arming is still possible
from the LCD keypad.
+
If the Zone Fault option is also enabled, the viola
-
tion of a Hold-Up Zone ONLY generates the Zone
Detector Fault event.
A
In order to comply with the EN50131-1 and
EN50131-3 standards, if your system has a
Hold-Up Zone, at least one “Hold-up device fault”
Zone must be present too: Hold-up and Zone
Fault options enabled.
Default: zone n. 6 (Terminal L2 of the Panel).
r
Zone Fault — Violation of an Zone Fault Zone — re
-
gardless of the status of its Partition — will generate
the Zone Detector Fault event.
Default: zone n. 5 (Terminal L1 of the Panel) and n. 6
(Terminal L2 of the Panel).
+
The Zone Fault Zone supports the Single End of
Line Balance ONLY.
A
In order to comply with the EN50131-1 and
EN50131-3 standards, in the system must be at
least one Zone Fault Zone.
r
Internal Siren Fault — Violation of an Internal Si
-
ren Fault Zone — regardless of the status of its Par
-
tition — will generate the Fault on Internal Siren
event.
Default: zone n. 7 (Terminal L3 of the Panel).
+
The Fault on Internal Siren Zone supports the
Single End of Line Balance ONLY.
A
In order to comply with the EN50131-1 and
EN50131-3 standards, in the system must be at
least one Internal Siren Fault Zone.
r
External Siren Fault — Violation of an External Si
-
ren Fault Zone — regardless of the status of its Par
-
tition — will generate the Fault on External Siren
event.
Default: zone n. 8 (Terminal L4 of the Panel).
+
The External Siren Fault Zone supports the Sin-
gle End of Line Balance ONLY.
A
In order to comply with the EN50131-1 and
EN50131-3 standards, in the system must be at
least one External Siren Fault Zone.
Roller Blind-Enabled This option must be enabled on
the Zones used for Roller blind contacts (This is valid
only for main board zones). If you enable this option you
must set the Roller Blind-Window and Pulses-Num
-
ber, that determine the zone violation.
Roller Blind-Window Set the time available to count
the set Pulses-Number so the zone will trigger an
alarm), as per the following example.
E.g. a zone with a Pulses-Number of 4 and a Roller
Blind-Window of 2 minutes, will signal violation when
its contact generates 4 pulses within 2 minutes.
Vibration-Enabled This option must be enabled on
the Zones used for Vibration detectors (This is valid
only for main board zones). If you enable this option you
must set the options Vibration-Sensitivity and
Pulses-Number, that determine the zone violation, as
per the following example.
