Switch forward - Forward travel direction
Switch backward - Reverse travel direction
In order to shift the transmission out of
Neutral
and into a travel direction, in
addition to the travel direction switch, the
Release/Neutral
switch (6) must
also be activated. To shift the transmission back to Neutral, press the
Release/Neutral
switch again.
When traveling, the particular speed range is preselected using the
Working
mode/Transport mode
switch (1).
Working mode
switch
activated
- Controlling the travel speed using the dial switch
(→ 8.2.6.6) and accelerator pedal (→ 8.2.6.5).
Transport mode
switch
activated
- Controlling the travel speed and engine speed
using the foot pedal (→ 8.2.6.5).
CAUTION! Risk of accident due to activating the parking brake
during the drive!
Activating the parking brake during the drive will lead to the machine
stopping immediately.
n Never activate the parking brake during the drive.
n The lap belt on the operator's seat must be fastened.
The
Parking brake
switch (4) must be activated when you leave/park the
machine. To release the parking brake, it is necessary to release an addi‐
tional activation lock on the
Parking brake
switch.
50-020-1011-900_EN
1.0 - © 2/15/2017
199
8 Operation
8.2 Operation of the machine
