540
SAFETY DEVICES AND EQUIPMENT
Studio ti 03312 540-04usa
284
12
1. “FIRE” rode safety pin
2. “FIRE” extinguisher tie rod
3. Fixed fire extinguisher in the engineroom
4. Firefighting system control panel
5. Firefighting panel on main electric panel
NOTICES
The images are referred to the US-version of
the yacht.
Fixed fire extinguisherControl panel
Main electric panelFirefighting system control
