540
CONTROL STATION
Studio ti 03312 540-04usa
94
6
23. Port ARG Anti-Rolling-Gyro switch (optional)
This switch allows to activate the port ARG Anti-Rolling-Gyro.
• ON: indicates that the ARG is powered by the relevant circuit
breaker.
• ACTIVE: indicates that the ARG stabilizer has reached its operation
speed.
24. Horn switch
This switch enables the operation of the horn.
25. Stern bilge pump switch
This switch allows the manual activation of the stern bilge pump.
26. Generator room bilge pump switch
This switch allows the manual activation of the bilge pump in the
generator room.
27. Engineroom bilge pump switch
This switch allows the manual activation of the bilge pump in the
engineroom.
28. Bow bilge pump switch
This switch allows the manual activation of the bow bilge pump.
29. Switch for magnetic compass backlighting
Allows the backlighting of magnetic compass.
30. Available
Push-button available for auxiliary system.
