Remove:
• circlip (1),
• drive gear (2),
• dowel pin (3),
• circlip (4).
Demontage:
• Sicherungsring (1)
• Verbindungsgetriebe zur Pumpe (2)
• Zapfen (3)
• Sicherungsring (4)
Déposer:
• circlip (1),
• pignon menant pompe (2),
• goupille (3),
• circlip (4).
Quitar:
• anillo elástico (1),
• engranaje conductor bomba (2),
• perno (3),
• anillo elástico (4).
