2- 1
1 Starting motor’s relay 5 Igntion spark plug
2 Voltage regulator 6 Battery (12V – 4 Ah)
3 Intermittence 7 Electric horn
4 AT coil 8 Key switch
LIGHTING EQUIPMENT
3
2
1
4
5
8
7
6
LIGHTING EQUIPMENT
