BCS-8xx series installation manual
22
2.2 Unpacking and Inspection of BCSC-38U/BCSC-24U cabinets
Weight is 280 kg for BCSC-38U and 180 kg for BCSC-24U cabinet
including four BCS-815: Lifting tools are needed!
Crush hazard! : Take care when unpacking (two persons are needed).
The packing of the BCSC-38U and the BCSC-24U cabinets have been designed to facilitate
the unpacking.
If you do not have a lifting system like a crane (by using the lifting ring screwed on the top of
the cabinet), you can use a sample forklift with the access ramp integrated to the packaging.
In this case, safety precaution should be absolutely taken when doing the unpacking
2.2.1 Unpacking of BCSC-38U/BCSC-24U cabinets using the lifting rings
Warning: Qualified Personal request
(Weight is 280 kg for BCSC-38U with 8 x
BCS-815)
(Weight is 180 kg for BCSC-24U with 4 x
BCS-815)
Using the lifting rings screwed on the top of
the cabinet
Fig. 23: Unpacking of BCSC-38U using lifting rings.
