BioLogic BCS-810 - BCS-815 Specifications

BCS-8xx series installation manual
63
8.4 BCS-815 Specifications
General Functions
BCS-815 module
Number of channel
8
Cell connection
4 terminal leads
Power
1700 W, 100-240 VAC*, 50-60 Hz
Cell Control
Compliance
Standard: 0-9 V (2-7 V without 0V)
Maximum current
±15 A continuous*
Maximum potential
See Power Contour Plots ch. 7.4
Voltage resolution
150 µV
Current resolution
0.0025% of FSR down to 76 nA
Current Accuracy
< 0.05% of value ±0.015% of FSR (other ranges)
< 0.1% of value ±0.015% of FSR (1 A range)
< 0.3% of value ±0.04% of FSR (10 A range)
Maximum power (ch/dis) per
channel
105 W
Voltage measurement
Ranges
0-10 V
Accuracy (DC)
< 0.3mV±0.01% of setting
Resolution
0.00038% of FSR down to 40 µV
Acquisition speed
2 ms
Noise (peak to peak 0-1kHz)
500 µV
Current measurement
Ranges
±10 A, ±1 A, ±100 mA, ±10 mA, ±1 mA
Accuracy (DC)
< 0.05% of value ±0.015% of FSR (other ranges)
< 0.1% of value ±0.015% of FSR (1 A range)
< 0.3% of value ±0.04% of FSR (10 A range)
Resolution (18-bit)
down to 20 nA
Electrometer
Input Impedance
100 MΩ || 6 pF typical
Input Bias Current
< 1 nA
Bandwidth (-3 dB)
4 kHz
Auxiliary Inputs / Outputs
1 analog input
± 5 V - 18 bits resolution
2 Digital inputs
TTL level Trigger input and Open Input
1 Digital output
TTL level Trigger output
1 Analog output
± 5V - 16 bits resolution
8 Thermocouples inputs
Type K; Accuracy ± 2°C**;
Measurement range: -25/200°C
* Maximum output power limited for mains supply voltage < 200VAC
** Accuracy can be D-rated for output currents >5A
