BCS-8xx series installation manual
25
2.3.1 Electrical equipment requirements
The electrical requirements for installation of the BCSC cabinets with a PDU-Unit, in Europe,
in the USA/Canada and in Japan are described in Table 11.
Table 11. Electrical equipment requirements
BCSC-24U
BCSC-38U
BCSC-12U
BCSC-6U
MAIN:
Power
Line
EU:
3 Phases + N + PE
230/400VAC 50/60Hz
30A
USA/CAN:
3 Phases + PE
120/208VAC 60Hz
30A
JP:
3 Phases + PE
200 VAC 50/60Hz
30 A
EU:
3 Phases + N + PE
230/400VAC 50/60Hz
50A
USA/CAN:
3 Phases + PE
120/208VAC 60Hz
50A
JP:
3 Phases + PE
200 VAC 50/60 Hz
50 A
PDU-Unit not needed
PDU-Unit not needed
AUX:
Logic
Line
100 to 240 VAC 10 A
100 to 240 VAC 10 A
100 to 240 VAC 150
W
100 to 240 VAC 60 W
Section of
incoming
cables
Main:10 mm² (7
AWG)
Aux:1.5 mm² (16
AWG)
Main:10 mm² (7AWG)
Aux: 1.5 mm² (16
AWG)
IEC C13/C14 power
cable
IEC C13/C14 power
cable
Maximum
Total Po-
wer
7.5 kW
15 kW
Depend on the in-
stalled BCS-8xx
model
Depend on the in-
stalled BCS-8xx
model
Protection
(included
in the
BCS-PDU)
Breakers + 30 mA
GFI
Breakers + 30 mA
GFI
Depend on the in-
stalled BCS-8xx
model
Depend on the in-
stalled BCS-8xx
model
