8.6 BCS-805 Specifications
General Functions
BCS-805 module
Number of channel
8
Cell connection
4 terminal leads+ Ground
Power
60 W, 100-240 VAC, 50-60 Hz
Cell Control
Compliance
0-10 V
Maximum current
±150 mA continuous
Maximum potential
10 V
Potential resolution
150 µV
Current resolution
0.0025% of FSR down to 760 pA
Current accuracy
< 0.05% of value ±0.015% of FSR
Maximum power (ch/disch)
1.5 W
Voltage measurement
Ranges
0-10 V
Accuracy (DC)
< 0.3mV±0.01% of setting
Resolution
0.00038% of FSR down to 38 µV
Acquisition speed
2 ms
Noise (peak to peak 0-100 kHz)
500 µV
Current measurement
Ranges
±100 mA, ±10 mA, ±1 mA, ±100 µA, ±10 µA
Accuracy (DC)
< 0.05% of value ±0.015% of FSR
Resolution (18-bit)
down to 0.2 nA
Electrometer
Input Impedance
> 50 GΩ || 6 pF typical
Input Bias Current
< 1 nA
Bandwidth (-3 dB)
4 kHz
Optional Auxiliary Inputs / Outputs
1 analog input
± 5 V– 18 bits resolution
1 Digital input
TTL level Trigger input
1 Digital output
TTL level Trigger output
1 Analog output
±5V -16 bits resolution
8.7 BCS-COM Specifications
General Functions
BCS-COM module
Front connections
1 RJ45 Ethernet connection
Rear connection
16 x RJ45 for module connections
1 BNC TTL output (optoMOS)
1 BNC TTL input
1 Phoenix 2 point output (opto-Triac)
Power
20 W, 100-240 VAC, 50-60 Hz
T range /°C
5-40
Emergency stop button
Yes (to be connected to the PDU unit or Open In)
