BioLogic BCS-810 - BCS-810 Specifications

BCS-8xx series installation manual
64
8.5 BCS-810 Specifications
General Functions
BCS-810 module
Number of channel
8
Cell connection
4 terminal leads + Ground
Power
220 W, 100-240 VAC, 50-60 Hz
Cell Control
Compliance
0-10 V
Maximum current
±1.5 A continuous
Maximum potential
10 V
Potential resolution
150 µV
Current resolution
0.0025% of FSR down to 7.6 nA
Current accuracy
< 0.05% of value ±0.015% of FSR
< 0.1% of value ±0.015% of FSR (1 A range)
Maximum power (ch/dis) per
channel
20 W
Voltage measurement
Ranges
0-10 V
Accuracy (DC)
< 0.3 mV±0.01% of setting
Resolution
0.00038% of FSR down to 40 µV
Acquisition speed
2 ms
Noise (peak to peak 0-100 kHz)
500 µV
Current measurement
Ranges
±1 A, ±100 mA, ±10 mA, ±1 mA, ±100 µA
Accuracy (DC)
< 0.05% of value ±0.015% of FSR
< 0.1% of value ±0.015% of FSR (1 A range)
Resolution (18-bit)
down to 2 nA
Electrometer
Input Impedance
> 50 GΩ || 6 pF typical
Input Bias Current
< 1 nA
Bandwidth (-3 dB)
4 kHz
Optional Auxiliary Inputs / Outputs
1 analog input
± 5 V– 18 bits resolution
1 Digital input
TTL level Trigger input
1 Digital output
TTL level Trigger output
1 Analog output
±5V -16 bits resolution
8 Thermocouples inputs
Type K; Accuracy ± 2°C;
Measurement range: -25/200°C
