Instruction manual NSF VSI / VSI W / VSI T / VSI
TW Maintenance
38065447002 en-US 65 / 101
Depositing table VSI, VSI W
Use both hands to lift table up a little on
the operator side and pull it to the front.
Fig.61: Remove depositing table
Light sensor
Pull the light barrier upwards out of the
holder and hang in to the holder of the
machine.
Fig.62: Remove light sensor
Conveyor VSI T
Tilt the lock on the belt support back-
wards in the direction of the arrow.
Fig.63: Unlock conveyor belt VSI T
