Product holder, 400mm carriage
Loosen star knob.
Remove product holder in upward direc-
tion.
Fig.73: Product holder
Feeding carriage, 400mm carriage
CAUTION!Risk of injury at driver spikes.
Take hold of product holder handle,
loosen locking lever and swivel upwards
until snapped into place.
Loosen star grip screw on the product
holder guide and remove product sup-
port plate.
Fig.74: Feeding carriage
Product holder
Loosen the star-grip handle on the prod-
uct holder guide.
Remove product holder in upward direc-
tion.
Fig.75: Product holder
