13.3 Warning messages
The different control methods and the hardware of the frequency inverter include
functions for continuous monitoring of the application. In addition to the messages
documented in the frequency inverter Operating Instructions, further warning mes-
sages are activated by the PROFINET communication module CM-PROFINET. The bit-
coded warning reports are issued via parameter
Warnings 270 according to the fol-
lowing pattern: Parameter
Warnings 270 is provided for read-out via a PLC, Parame-
ter
Warnings 269 provides the information, including a brief description in VPlus and
the KP500 control unit.
Warning messages
Bit no.
Warning
code
Description
0
0x0001
Warning Ixt
1
0x0002
Warning short-time Ixt
2
0x0004
Warning long-time Ixt
3
0x0008
Warning heat sink temperature Tk
4
0x0010
Warning inside temperature Ti
5
0x0020
Warning Limit
6
0x0040
Warning Init
7
0x0080
Motor temperature warning
8
0x0100
Warning mains failure
9
0x0200
Warning motor circuit breaker
10
0x0400
Warning Fmax
11
0x0800
Warning analog input MFI1A
12
0x1000
Warning analog input A2
13
0x2000
Warning Systembus
14
0x4000
Warning Udc
15
0x8000
Warning Application warning status 367
The meanings of the individual warnings are described in detail in the frequency in-
verter Operating Instructions.
