13.5 Error messages
The error code stored following a fault comprises the error group FXX (high-byte,
hexadecimal) and the code YY (low-byte, hexadecimal).
Communication error
Key
Meaning
Motion
F04
04
Control Deviation Position Controller
Control
F14
42
Pos. SW Limit Switch
Interface
43
Neg. SW Limit Switch
44
Pos. SW Limit Sw. < Neg. SW Limit Sw.
45
Pos. and Neg. HW-Lim Switch Simultaneously
46
Limit Switch Incorrect Wired
47
Pos. HW Limit Switch
48
Neg. HW Limit Switch
51
Switch: Pos. Dir. Blocked
52
Switch: Neg. Dir. Blocked
53
System bus-Synchronization not activated
60
Pos. HW Limit Sw.: Non-permissible signal source
61
Pos. HW Limit Sw.: Input deactivated by PWM /FF input
62
Pos. HW Limit Sw.: Input deactivated of index controller
63
Pos. HW Limit Sw.: wrong mode for MFI1
64
Pos. HW Limit Sw.: Input deactivated by encoder 1
65
Pos. HW Limit Sw.: Input deactivated by encoder 2
66
Pos. HW Limit Sw.: wrong mode for EM-S1IOD
70
Neg. HW Limit Sw.: Non-permissible signal source
71
Neg. HW Limit Sw.: Input deactivated by PWM /FF input
72
Neg. HW Limit Sw.: Input deactivated of index controller
73
Neg. HW Limit Sw.: wrong mode for MFI1
74
Neg. HW Limit Sw.: Input deactivated by encoder 1
75
Neg. HW Limit Sw.: Input deactivated by encoder 2
76
Neg. HW Limit Sw.: wrong mode for EM-S1IOD
F15
xx
User-Defined Error in Motion Block xx (1 ≤ xx ≤ 32)
70
No Homing Done
71
Homing Encoder-Mode without Z-Impulse
72
Both Directions Locked
73
No Touch Probe Signal Detected
74
M/S Position Correction: Master Position source not set. Check chapter
11.4.7.1 “Master/Slave Position Correction”.
PROFINET
F27
14
Communication loss to PLC*
50
PNIO Configuration Error (wrong configuration of cyclic data objects
PZD)
* This message is only displayed if Bus Error Behaviour 388 ≠ 0.
The current error can be read via parameter Current error 260.
Parameter Current error 259 indicates the current error as plain text
in the control
panel and the VPlus PC control software.
In addition to the error messages mentioned, there are other error messages speci-
fied in the Operating Instructions. The errors of the Motion Control Interface (F14xx,
F15xx) are described in detail in the “Positioning” application manual.
