BONFIGLIOLI Vectron ACTIVE CUBE - Data Set Parameter Access

PKW range
Designation
PKE
IND
PWE-high
PWE-low
Contents
Parameter
code
Index
Parameter
value
high word
Parameter
value
low word
High
Byte
Low
Byte
High
Byte
Low
Byte
High
Byte
Low
Byte
High
Byte
Low
Byte
0x34
0xB2
0
0
0x00
0x00
0x00
0x00
Byte no.
0
1
2
3
4
5
6
7
Response from slave:
AK
= 2 (order code = transmit long parameter value)
PNU
= 1202 (=0x4B2)
IND
= 0
PWEh
= 0x0001
PWEI
= 0xE078
PKW range
Designation
PKE
IND
PWE-high
PWE-low
Contents
Parameter
code
Index
Parameter
value
high word
Parameter
value
low word
High
Byte
Low
Byte
High
Byte
Low
Byte
High
Byte
Low
Byte
High
Byte
Low
Byte
0x24
0xB2
0
0
0x00
0x01
0xE0
0x78
Byte no.
0
1
2
3
4
5
6
7
If various parameters of an index are to be read, it will be sufficient to set index
access via 1201 once at the beginning.
8.2 Parameter access through reading/writing of data sets
The PROFINET communication module CM-PROFINET features the PROFINET data
set access function. This feature can be used as an alternative to the PKW commu-
nication object in the data exchange object. The PKW object is always sent to the
bus, regardless of whether it is currently being used or not. Thus, it produces un-
necessary bus load.
40 CM-PROFINET 10/13
