8.1.5.1 Communication examples
Parameters
Settings
No.
Description
Type
Write/
read
Format
Min.
Max.
Factory
settings
400
Switching fre-
quency
P-W
S/L
x
1
8
2
480
Fixed
frequency 1
P[I]-D
S/L
xxxx.xx
Hz
-999.00
999.00
5.00
Example 1
Parameter 400 is a type int word (P-W), is not data set switchable and is to be read.
Order from master:
AK
= 1 (order code = read parameter value)
PNU
= 400 (= 0x190)
IND
= 0
PWEh
= 0
PWEl
= 0
PKW range
Designa-
tion
PKE
IND
PWE-high
PWE-low
Contents
Parameter
ID
Index
Parameter value
high word
Parameter value
low word
High
Byte
Low
Byte
High
Byte
Low
Byte
High
Byte
Low
Byte
High
Byte
Low
Byte
0x11
0x90
0
0
0
0
0
0
Byte no.
0
1
2
3
4
5
6
7
Response from slave:
AK
= 1 (response code = transmit int/uint parameter value)
PNU
= 400 (= 0x190)
IND
= 0
PWEh
= 0
PWEl
= value
PKW range
Designa-
tion
PKE
IND
PWE-high
PWE-low
Contents
Parameter
ID
Index
Parameter value
high word
Parameter value
low word
High
Byte
Low
Byte
High
Byte
Low
Byte
High
Byte
Low
Byte
High
Byte
Low
Byte
0x11
0x90
0
0
0
0
0
Value
Byte no.
0
1
2
3
4
5
6
7
Example 2
Parameter 480 is a type long double word (P[I]-D), is data set switchable and is
to be written. The target data set is Data set 3.
Reference value = -300.00 Hz (-30000 is transmitted)
According to integer arithmetics, the negative value is represented as follows:
0xFFFF8AD0
