• Start the TCP-IP configuration in VPlus and enter the device name as the “Host
name”.
The IP settings must also be made again.
6.4 Alarm messages
In the case of a frequency inverter fault, CM-PROFINET sends an alarm message. This
function can be deactivated via parameter Profibus/PROFINET Diagnostic/Alarm
Message 1444.
Diagnostic/Alarm Message 1444
Function
0 - Off
No alarm message in the case of a frequency
inverter fault.
1 - On
Alarm message in the case of a frequency
inverter fault. Factory setting.
List of Alarm messages
Error Type
Error Text
Help Text
257
Ixt Overload
F01nn Inverter rated current exceeded
258
Heatsink temperature
F02nn Heatsink temperature too high
259
Inside temperature
F03nn Inside temperature too high
260
Motor connection
F04nn Motor temperature, protection switch, V-belt
monitoring, phase failure
261
Output current
F05nn Overload, short circuit, earth fault, asymmet-
ric current, phase monitoring
262
Internal Fault
F06nn Internal Fault
263
DC-Link voltage
F07nn DC-Link voltage too low/high, brake/motor
chopper threshold too small
264
Electronic voltage
F08nn Electronic voltage DC 24V too low/high
265
Pre-charging relay
F09nn Pre-charging relay faulted
272
Brake chopper
F10nn Brake chopper faulted
273
Output frequency
F11nn Output frequency exceeded maximum fre-
quency
274
Safety function STO
F12nn Diagnosis error of function STO, STOA/STOB
monitoring
275
Motor load
F13nn Earth fault, IDC compensation limit, mini-
mum current monitoring
276
Control connection
F14nn Encoder signals, external error
277
Table travel record
F15nn Table travel record, error in motion blocks
278
Parameter
F16nn Parameter error
279
Encoder
F17nn Encoder error
289
CAN-Systembus slave error
F21nn CAN-Systembus slave node id = nn reports
error
290
CAN-System bus
F22nn CAN-Systembus error
292
EM-Module
F24nn Unknown EM-Module
304
Application
F30nn Application error
511
Generic
Fxxxx Generic error
