11.3.4 Sequence example
In configurations without Motion Control (Configuration 30 ≠ x40), the PLC must
send the correct sequence:
1
Control word =
0x0000
Disable voltage
2
Control word =
0x0006
Shut down
3
Control word =
0x0007
Switch On
4
Control word =
0x000F
Enable operation
OR
1
Control word =
0x0000
Disable voltage
2
Control word =
0x000F
Enable operation
In configurations without Motion Control (Configuration 30 ≠ x40), the second
(shortened) sequence can be used, because transition 4‘ is available in these config
u-
rations.
76 CM-PROFINET 10/13
