8.1.6 Handling of index parameters / cyclic writing
Index parameters are used for various ACU functions. Here, 16 or 32 indexes are
used instead of the 4 data sets. For each function, the individual indexes are ad-
dressed separately via an index access parameter. Via the indexing parameter, you
can select if the data is to be written to EEPROM or RAM.
Function
Parameters
Index range
Indexing
parameter
Write
EEPROM
and read
Write
RAM
Positioning
1202 Target position / distance
1203 Speed
1204
Acceleration
1205
Ramp Rise time
1206
Deceleration
1207
Ramp Fall time
1208
Motion mode
1209
Touch-Probe Window
1210 Touch-Probe-Error: Next Mo-
tion Block
1211
No. of Repetitions
1212 Delay
1213
Delay: Next Motion Block
1214 Event 1
1215 Event 1: Next Motion Block
1216 Event 2
1217 Event 2: Next motion block
1218 Digital signal 1
1219 Digital signal 2
1247 Digital signal 3
1248 Digital signal 4
1260 Interrupt-Event 1
1261 Int.-Event 1: Eval.-Mode
1262 Int. event 1: Next motion block
1263 Interrupt-Event 2
1264 Int.-Event 2: Eval.-Mode
1265 Int. event 2: Next motion block
0
1)
;
1…32
33
1)
;
34…65
1200 Write
1201 Read
PLC func-
tion
(Function
Table)
1343 FT-Instruction
1344 FT-Input 1
1345 FT-Input 2
1346 FT-Input 3
1347 FT-Input 4
1348 FT-Parameter 1
1349 FT-Parameter 2
1350 FT-Target Output 1
1351 FT-Target Output 2
1352
FT-Commentary
0
1)
;
1…32
33
1)
;
34…65
1341 Write
1342 Read
Multiplexer
1252 Mux Input
0
1)
;
1…16
17
1)
;
18…33
1250 Write
1251 Read
CANopen
multiplexer
1422 CANopen Mux Input
0
1)
;
1…16
17
1)
;
18…33
1420 Write
1421 Read
36 CM-PROFINET 10/13
