3.2 Initialization time
When the frequency inverter is turned on, the communication module must be initialized in addition
to the frequency inverter. The initialization can take up to 20 seconds.
Wait until the initialization phase is complete before starting the communication (RUN
LED).
4 First commissioning
For first commissioning, you should be familiar with the followings steps and the de-
scribed functions:
• Installation of the module
Chapter
5.1
• Selection of device control Local/Remote 412
Chapter
11
• Commissioning of device functions via PLC
o Setting the station address
Chapter
6.3
o Setting the process data
Chapter
7
o Fault Reaction
Chapter
6.5
 Resetting errors
Chapter
8.5
o Parameter access
Chapter
8.1
• Setting reference values:
o Reference speed in speed-controlled
configuration x10, x11, x15, x16, x30, x60
Chapter
11.3
o Reference value in position configuration x40
Chapter
10.2
 Velocity mode vl
Chapter
10.2.7
 Profile velocity mode pv
Chapter
10.2.8
 Profile position mode
Chapter
10.2.6
 Homing mode
Chapter
10.2.9
 Table travel record mode
Chapter
10.2.10
 Move Away from Limit Switch
Chapter
10.3
 Mode of Operation change
Chapter
10.2.2
• Diagnosis:
Chapter
11, 12
