BONFIGLIOLI Vectron ACTIVE CUBE - Parameter List

12 Parameter List
The parameter list is structured according to the menu branches of the control unit.
For better overview, the parameters are marked with pictograms:
The parameter is available in the four data sets.
The parameter value is set by the SETUP routine.
This parameter cannot be written when the frequency inverter is in operation.
12.1 Actual values
No.
Description
Unit
Indication range
Chapter
Actual values of frequency inverter
228
Internal reference frequency
Hz
-1000.00 ... 1000.00
11.3.3
249
Active dataset
-
1 ... 4
11
250
Digital inputs
-
0 … 255
11.1
260
Current error
-
0 ... 0xFFFF
13.5
270
Warnings
-
0 ... 0xFFFF
13.3
274
Warning application
-
0 ... 0xFFFF
13.4
282
Reference bus frequency
Hz
-1000.00 ... 1000.00
11.3.3
283
Reference ramp frequency
Hz
-1000.00 ... 1000.00
11.3.3
Actual values of Motion Control Interface (MCI)
1108 Actual Position u
-2147483647 …
2147483647
10.2.4
1109 Act. Contouring Error u
-2147483647 …
2147483647
10.2.4
Parameters Current error 260, Warnings 270 and Application warnings 274 are
only accessible via the communication channel of objects PPO1 and PPO2. They ca
n-
not be addressed via the VPlus control software or the KP500 control unit.
124 CM-PROFINET 10/13
