• When an object is set to a certain source number, it must be ensured that the
relevant objects have the preset values at the same place. This method is the
same as is the one used in the case of objects for Systembus transmission
(transmit objects).
• Boolean inputs represent Boolean objects.
• Word inputs represent percentage, current or torque objects.
• Long inputs represent frequency or position objects.
The displayed PDP active current depends on the type of control. In the case of
field-oriented controls, the torque-forming current is displayed. In applications with
U/f characteristic control, the active current also measured for the torque will be
displayed.
The PDP effective current will always be positive. The torque-forming current and
the active current are signed.
A positive current sign corresponds to motor operation mode.
A negative current sign corresponds to generator operation mode.
Current standardization
Standardization
Reference
Value
Binary
Decimal
Hexadecimal
+ 100%
+ 2
14
16384
0x4000
Possible range = ±200% = +32768 to -32768 = 0x8000 through 0x7FFF
For internal standardization, the data set switchable parameter Rated Current 371
is used as the reference value.
Parameters
Settings
No.
Description
Min.
Max.
Factory set-
ting
371
Rated current
0.01 · I
FUN
10 · I
FUN
I
FUN
46 CM-PROFINET 10/13
