Status word
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Bit
0
Ready to switch on
1
Switched on
2
Operation enabled
3
Fault
4
Voltage enabled
5
Quick stop (low active)
6
Switch on disabled
7
Warning
8
Phasing Done or
M/S Correction Done
9
Remote
10
Target reached / In gear
11
Internal limit active
12
M/S Position Correction
successful
13
Following error
14
-
15
Warning 2
WARNING
Dangerous state due to faulty parameterization
•
The function Master/Slave Position Correction is only allowed to be used after
complete setup of this function. Check for parameter setup chapter 11.4.7.1
“Master/Slave Position Correction”.
