Boss VF-1 - Connecting a Keyboard; Connecting a MIC

15
Section 1. Producing Sound
Section 1
Connecting a keyboard
* Normally you should set the LEVEL switch to -20 dBm.
* When inputting in mono, make connections to the INPUT L
(MONO) jack.
* When outputting in mono, make connections to the OUTPUT L
(MONO) jack.
fig.1-04
Connecting a mic
* Set the LEVEL switch to match the level of the mixer to which
the VF-1 is connected.
fig.1-42
Howling could be produced depending on the location of
mics relative to speakers. This can be remedied by:
1. Changing the orientation of the mic(s).
2. Relocating mic(s) at a greater distance from speakers.
3. Lowering volume levels.
Mixer
INPUT R INPUT L
Keyboard
OUTPUT R OUTPUT L
Mixer
Microphone
RETURN
INPUT
SEND
