Boss VF-1 - Pb13 Reverb 2

67
Algorithm list
Section 4
P
B
13 REVERB 2
fig.4-202
This connects an equalizer, chorus, and reverb in series.
After using the equalizer to adjust the input sound, you can use chorus and reverb to create spacious reverb.
In this Algorithm, what you have set with the DIRECT MIX (p.46) will have effect.
4BAND EQ (Equalizer)
EFFECT OFF, ON
LOW EQ -20–+20 (dB)
HIGH EQ -20–+20 (dB)
LEVEL -20–+20 (dB)
LO-MD F 100–10.0 k (Hz)
LOW-MID Q 0.5–16.0
LOW-MID EQ -20–+20 (dB)
HI-MD F 100–10.0 k (Hz)
HI-MID Q 0.5–16.0
HI-MID EQ -20–+20 (dB)
STEREO CHORUS
EFFECT OFF, ON
POLARITY SYNC, INVERT
RATE 0–100, BPM:
DEPTH 0–100
PRE DELAY 0.0–40.0 (msec)
LOW CUT FLAT, 55–800 (Hz)
HIGH CUT 700–11 k (Hz), FLAT
EFFECT LEVEL 0–100
DIRECT SWITCH OFF, ON
REVERB
EFFECT OFF, ON
TYPE ROOM, HALL
SIZE 1–10
REVERB TIME 0.1–32.0 (sec)
BALANCE DIR:FX 100:0–0:100
EFFECT LEVEL 0–100
PRE DELAY 0–200 (msec)
DENSITY 0–100
EARLY REF LEVEL 0–100
LOW DAMP GAIN -36.0–0.0 (dB)
LOW DAMP FREQUENCY 55–4.0 k (Hz)
HIGH DAMP GAIN -36.0–0.0 (dB)
HIGH DAMP FREQUENCY 4.0 k–20.0 k (Hz)
HIGH CUT FILTER 200–20.0 k (Hz)
MASTER
<MASTER>
LEVEL 0–100
BPM 40–250, MIDI, GLOBAL
<FV: FOOT VOLUME>
FOOT LEVEL 0–100
Input L
Input R
Output L
Output R
Direct Level
Direct Level
REVERB
4BAND EQ
CHORUS
CHORUS
FV
