Algorithm list
P
B
32 VOCAL CANCELER
fig.4-225
When a stereo source such as CD or DAT is input to this effect, sounds that are located in the center (such as vocals or bass) will
be removed. A four-band equalizer is provided on the output.
* Depending on the musical source, desired sounds may be removed, or there may be other ways in which the result is not as you wish. In
particular, the desired effect will not be obtained on musical sources with deep reverb, or if the sound you wish to cancel is not located in the
center.
VOCAL CANCELER
EFFECT OFF, ON
BALANCE 0–100
RANGE LOW 20–2000 (Hz)
RANGE HIGH 1.0 k–20.0 k (Hz)
NS. SUPPRESSOR (Noise Suppressor)
EFFECT OFF, ON
THRESHOLD 0–100
RELEASE 0–100
4BAND EQ (Equalizer)
EFFECT OFF, ON
LOW EQ -20–+20 (dB)
HIGH EQ -20–+20 (dB)
LEVEL -20–+20 (dB)
LO-MD F 100–10.0 k (Hz)
LOW-MID Q 0.5–16.0
LOW-MID EQ -20–+20 (dB)
HI-MD F 100–10.0 k (Hz)
HI-MID Q 0.5–16.0
HI-MID EQ -20–+20 (dB)
MASTER
<MASTER>
LEVEL 0–100
<FV: FOOT VOLUME>
FOOT LEVEL 0–100
Input L
Input R
Output L
Output R
FV
VOCAL
CANCELER
NS.
SUPPRESSOR
4BAND EQ
