71
Algorithm list
Section 4
P
B
17 CHORUS RSS
fig.4-209
The output of the chorus is connected to RSS. The left-channel sound is positioned at 90 degrees left, and the right-channel sound
is positioned at 90 degrees right.
A four-band equalizer is provided on the input.
In this Algorithm, what you have set with the DIRECT MIX (p.46) will have effect.
4BAND EQ (Equalizer)
EFFECT OFF, ON
LOW EQ -20–+20 (dB)
HIGH EQ -20–+20 (dB)
LEVEL -20–+20 (dB)
LO-MD F 100–10.0 k (Hz)
LOW-MID Q 0.5–16.0
LOW-MID EQ -20–+20 (dB)
HI-MD F 100–10.0 k (Hz)
HI-MID Q 0.5–16.0
HI-MID EQ -20–+20 (dB)
STEREO CHORUS
EFFECT OFF, ON
POLARITY SYNC, INVERT
RATE 0–100, BPM:
DEPTH 0–100
PRE DELAY 0.0–40.0 (msec)
LOW CUT FLAT,55–800 (Hz)
HIGH CUT 700–11 k (Hz), FLAT
EFFECT LEVEL 0–100
DIRECT SWITCH OFF, ON
RSS SWITCH OFF, ON
MASTER
<MASTER>
LEVEL 0–100
BPM 40–250, MIDI, GLOBAL
<FV: FOOT VOLUME>
FOOT LEVEL 0–100
Input L
Input R
CHORUS
Output L
Output R
Direct Switch
Direct Switch
RSS
4BAND EQ
RSS
FV
CHORUS
To Next Page
