77
Algorithm list
Section 4
P
B
23 MIC SIMULATOR
fig.4-228
With this effect, sounds that were picked up by a standard dynamic mic, pin mic, or direct line, can be converted to produce the
impression that the sounds were recorded on an expensive condenser mic or a special studio mic.
A proximity effect or a sense of distance from the mic can also be added.
* We recommended the microphone should be pre-amplified (by a mixer, etc.).
Lch & Rch: MIC CONV (Mic Converter)
EFFECT OFF, ON
INPUT DR-20, SML.DY, HED.DY, MIN.CN, FLAT
OUTPUT SML.DY, VOC.DY, LRG.DY, SML.CN,
LRG.CN, VNT.CN, FLAT
PHASE NOR, INV
* If “MIC.CN” is selected for Input, it will be possible to select
only “SML.DY” or “LRG.CN” for Output.
Lch & Rch: BCF (Bass cut filter)
EFFECT OFF, ON
FREQUENCY THRU, 20–2000 (Hz)
Lch & Rch: DISTANCE
EFFECT OFF, ON
PROX.FX -12–+12
TIME 0–3000 (cm)
Lch & Rch: LIMITER
EFFECT OFF, ON
THRESHOLD -60–0 (dB)
ATTACK 0–100
RELEASE 0–100
DETECT HPF THRU, 20–2000 (Hz)
LEVEL -60–+4 (dB)
MASTER
<MASTER>
LINK OFF, ON
LEVEL 0–100
<FV: FOOT VOLUME>
FOOT LEVEL 0–100
MIC CONV DISTANCE LIMITER
MIC CONV DISTANCE LIMITER
Link
Input L
Input R
Output L
Output R
FV
BASS CUT FILTER
BASS CUT FILTER
