Boss VF-1 - PB21 Multitap DELAY (20 TAP)

75
Algorithm list
Section 4
P
B
21 MultiTAP DELAY (20 TAP)
fig.4-223
This delay lets you make independent settings for twenty separate delay sounds.
A four-band equalizer is provided on the input.
In this Algorithm, what you have set with the DIRECT MIX (p.46) will have effect.
4BAND EQ (Equalizer)
EFFECT OFF, ON
LOW EQ -20–+20 (dB)
HIGH EQ -20–+20 (dB)
LEVEL -20–+20 (dB)
LO-MD F 100–10.0 k (Hz)
LOW-MID Q 0.5–16.0
LOW-MID EQ -20–+20 (dB)
HI-MD F 100–10.0 k (Hz)
HI-MID Q 0.5–16.0
HI-MID EQ -20–+20 (dB)
MULTI TAP DELAY
EFFECT OFF, ON
RATIO 1–100 (%)
TAP [1]– [20] DELAY TIME 0–2800 (msec), BPM:
TAP [1]– [20] FINE TIME 0–20 (msec)
TAP [1]– [20] PAN L:R 100:0–0:100
TAP [1]– [20] LEVEL 0–100
FB DELAY 0–2800 (msec), BPM:
FB FINE 0–20 (msec)
FB LEVEL 0–100
LOW CUT FLAT, 55–800 (Hz)
HIGH CUT 700–11 k (Hz), FLAT
DIR LEVEL 0–100
FX LEVEL 0–120
MASTER
<MASTER>
LEVEL 0–100
BPM 40–250, MIDI, GLOBAL
<FV: FOOT VOLUME>
FOOT LEVEL 0–100
Input R
Output R
MULTI TAP DELAY
4BAND EQ
Pan 1
Pan 2
Pan 20
Feedback
Direct Level
Level 1
Level 2
Level 20
Direct Level
Input L
Output L
FV
