Boss VF-1 - PB2 GUITAR MULTI 2

52
Algorithm list
P
B
2 GUITAR MULTI 2
fig.4-232
This is a multi-effect for guitar that contains a preamp/speaker simulator.
The SFX (special effects) settings allow you to use an acoustic simulator, bass guitar simulator, or pickup simulator etc.
SFX lets you select one of the following
effects.
SFX: AC (Acoustic Guitar Simulator)
BS (Bass Guitar Simulator)
SG (Slow Gear)
FB (Feedbacker)
PIC (Pick Up Simulator)
TR (Tremolo/Pan)
PREAMP/SP.SIM and SFX can be moved to the
( ) locations shown in the diagram.
COMPRESSOR/LIMITER
EFFECT OFF, ON
SELECT COMP, LIMIT
<COMP: COMPRESSOR>
SUSTAIN 0–100
ATTACK 0–100
TONE -50–+50
LEVEL 0–100
<LIMIT: LIMITER>
THRESHOLD 0–100
RELEASE 0–100
TONE -50–+50
LEVEL 0–100
SFX (Special Effect)
EFFECT OFF, ON
SELECT AC, BS, SG, FB, PIC, TR
<AC: ACOUSTIC GtSIM>
TOP 0–100
BODY 0–100
LEVEL 0–100
POSITION Can be moved to the ( ) locations shown
in the diagram.
<BS: BASS GTR SIM>
CHARACTER LOOSE, TIGHT
FX LEVEL 0–100
DIR LEVEL 0–100
POSITION Can be moved to the ( ) locations shown
in the diagram.
<SG: SLOW GEAR>
SENS 0–100
RISE TIME 0–100
POSITION Can be moved to the ( ) locations shown
in the diagram.
<FB: FEEDBACKER>
MODE OSC, BOOST
RISE TIME 0–100
RISE TIME 0–100 MODE = OSC
F.B LEVEL 0–100 MODE = OSC
F.B LEVEL 0–100 MODE = OSC
VIB RATE 0–100 MODE = OSC
VIB DEPTH 0–100 MODE = OSC
F.B DEPTH 0–100 MODE = BOOST
FEEDBACK TONE NORMAL, +1OCT MODE = BOOST
POSITION Can be moved to the ( ) locations shown
in the diagram.
<PIC: PICKUP SIM>
TYPE 'S' to 'H', 'H' to 'S', 'H' to 'HF'
TONE -50–+50
LEVEL 0–100
POSITION Can be moved to the ( ) locations shown
in the diagram.
<TR: TREMOLO/PAN>
MODE TREMOLO, PAN
WAVE SHAPE 0–100
RATE 0–100, BPM:
DEPTH 0–100
POSITION Can be moved to the ( ) locations shown
in the diagram.
Input L
Input R
COMPRESSOR /
LIMITER
NS.
SUPPRESSOR
SFX WAH
DELAY
FV
CHORUS REVERB
PREAMP/
SP.SIM
4BAND EQ
Output L
Output R
