55
Algorithm list
Section 4
DISTORTION
EFFECT OFF, ON
TYPE TURBO OD, BASS OD, HARD DS, FUZZ 1,
FUZZ 2
DRIVE 0–100
BASS -50–+50
TREBLE -50–+50
FX LEVEL 0–100
DIR LEVEL 0–100
4BAND EQ (Equalizer)/T-WAH
EFFECT OFF, ON
SELECT 4BAND EQ, T-WAH
<4BAND EQ>
LOW EQ -20–+20 (dB)
HIGH EQ -20–+20 (dB)
LEVEL -20–+20 (dB)
LO-MD F 100–10.0 k (Hz)
LOW-MID Q 0.5–16.0
LOW-MID EQ -20–+20 (dB)
HI-MD F 100–10.0 k (Hz)
HI-MID Q 0.5–16.0
HI-MID EQ -20–+20 (dB)
<T-WAH>
SENS 0–100
START DOWN, UP
STOP 0–100
RESONANCE 0–100
FX LEVEL 0–100
DIR LEVEL 0–100
NS. SUPPRESSOR (Noise Suppressor)
EFFECT OFF, ON
THRESHOLD 0–100
RELEASE 0–100
DELAY
EFFECT OFF, ON
TYPE SINGLE, TAP
DELAY TIME 0–1800 (msec), BPM:
FINE TIME 0–20 (msec)
TAP TIME 0–100 (%) TYPE = TAP
FEEDBACK 0–100
HIGH CUT 700–11 k (Hz), FLAT
FX LEVEL 0–120
MOD (Modulation)
EFFECT OFF, ON
SELECT FL, PH, CE
<FL: FLANGER>
RATE 0–100, BPM:
DEPTH 0–100
MANUAL 0–100
RESONANCE 0–100
SEPARATE 0–100
LEVEL 0–100
POSITION Can be moved to the ( ) locations shown
in the diagram.
<PH: PHASER>
RATE 0–100, BPM:
DEPTH 0–100
MANUAL 0–100
RESONANCE 0–100
POSITION Can be moved to the ( ) locations shown
in the diagram.
<CE: CHORUS>
MODE MONO, ST.
RATE 0–100, BPM:
DEPTH 0–100
PRE DELAY 0.0 –40.0 (msec)
LOW CUT FLAT, 55–800 (Hz)
FX LEVEL 0–100
POSITION Can be moved to the ( ) locations shown
in the diagram.
REVERB
EFFECT OFF, ON
TYPE ROOM1, ROOM2, HALL1, HALL 2, PLATE
REVERB TIME 0.1–10.0 (sec)
PRE DELAY 0–100 (msec)
LOW CUT 55–800 (Hz)
HIGH CUT 700–11 k (Hz), FLAT
DENSITY 0–10
FX LEVEL 0–100
MASTER
<MASTER>
LEVEL 0–100
BPM 40–250, MIDI, GLOBAL
<FV: FOOT VOLUME>
FOOT LEVEL 0–100
